DC 무브러시 팬(BLDC)
| 사진 | 제조업체 부품 번호 | 재고 상태 | 수량 | 데이터시트 | 시리즈 | 패키징 | 제품 상태 | 전압 - 정격 | 크기/치수 | 너비 | 공기 흐름 | 정압 | 베어링 유형 | 팬 유형 | 기능 | 소음 | 전력(와트) | RPM | 종단 | 침투 방지 | 작동 온도 | 승인 기관 | 무게 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
15050VA-24Q-GA-00DC AXIAL FAN |
0 |
|
데이터시트 |
15050VA | Box | Active | 24VDC | Rectangular/Rounded - 172.7mm L x 150mm H | 50.80mm | 304.0 CFM (8.51m³/min) | 1.072 in H2O (267.0 Pa) | Ball | Tubeaxial | Auto Restart | 64.0dB | 31.2 W | 4000 RPM | 2 Wire Leads | IP69K - Dust Tight, High Temp Water Jets, Waterproof | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
W2G115-AE53-01FAN AXIAL 127X38MM 12VDC WIRE |
0 |
|
데이터시트 |
W2G115 | Bulk | Obsolete | 12VDC | Square - 127mm L x 127mm H | 38.00mm | 130.0 CFM (3.64m³/min) | - | Ball | Tubeaxial | - | 48.0dB(A) | 5.9 W | - | 2 Wire Leads | - | - | - | 1.6 lbs (725.7 g) |
|
|
MS1751L12B1+6-FHR-2EMFAN AXIAL 171X51.5MM 12VDC WIRE |
0 |
|
데이터시트 |
MS1751-H | Bulk | Active | 12VDC | Rectangular/Rounded - 171mm L x 153mm H | 51.50mm | 184.4 CFM (5.16m³/min) | 0.630 in H2O (156.9 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 53.0dB(A) | - | 3000 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | - | - | 1.5 lbs (670.0 g) |
|
|
MS1751M12B1+6-FHR-2EMFAN AXIAL 171X51.5MM 12VDC WIRE |
0 |
|
데이터시트 |
MS1751-H | Bulk | Active | 12VDC | Rectangular/Rounded - 171mm L x 153mm H | 51.50mm | 352.1 CFM (9.86m³/min) | 1.000 in H2O (249.1 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 66.0dB(A) | - | 4500 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | - | - | 1.5 lbs (670.0 g) |
|
|
MS1751H12B1+6-FHR-2EMFAN AXIAL 171X51.5MM 12VDC WIRE |
0 |
|
데이터시트 |
MS1751-H | Bulk | Active | 12VDC | Rectangular/Rounded - 171mm L x 153mm H | 51.50mm | 418.0 CFM (11.70m³/min) | 1.640 in H2O (408.5 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 71.0dB(A) | - | 5500 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | - | - | 1.5 lbs (670.0 g) |
|
|
MS1751L24B1+6-FHR-2EMFAN AXIAL 171X51.5MM 24VDC WIRE |
0 |
|
데이터시트 |
MS1751-H | Bulk | Active | 24VDC | Rectangular/Rounded - 171mm L x 153mm H | 51.50mm | 184.4 CFM (5.16m³/min) | 0.630 in H2O (156.9 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 53.0dB(A) | - | 3000 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | - | - | 1.5 lbs (670.0 g) |
|
|
MS1751M24B1+6-FHR-2EMFAN AXIAL 171X51.5MM 24VDC WIRE |
0 |
|
데이터시트 |
MS1751-H | Bulk | Active | 24VDC | Rectangular/Rounded - 171mm L x 153mm H | 51.50mm | 352.1 CFM (9.86m³/min) | 1.000 in H2O (249.1 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 66.0dB(A) | - | 4500 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | - | - | 1.5 lbs (670.0 g) |
|
|
MS1751H24B1+6-FHR-2EMFAN AXIAL 171X51.5MM 24VDC WIRE |
0 |
|
데이터시트 |
MS1751-H | Bulk | Active | 24VDC | Rectangular/Rounded - 171mm L x 153mm H | 51.50mm | 418.0 CFM (11.70m³/min) | 1.640 in H2O (408.5 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 71.0dB(A) | - | 5500 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | - | - | 1.5 lbs (670.0 g) |
|
|
MS1751L48B1+6-FHR-2EMFAN AXIAL 171X51.5MM 48VDC WIRE |
0 |
|
데이터시트 |
MS1751-H | Bulk | Active | 48VDC | Rectangular/Rounded - 171mm L x 153mm H | 51.50mm | 184.4 CFM (5.16m³/min) | 0.630 in H2O (156.9 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 53.0dB(A) | - | 3000 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | - | - | 1.5 lbs (670.0 g) |
|
|
MS1751M48B1+6-FHR-2EMFAN AXIAL 171X51.5MM 48VDC WIRE |
0 |
|
데이터시트 |
MS1751-H | Bulk | Active | 48VDC | Rectangular/Rounded - 171mm L x 153mm H | 51.50mm | 352.1 CFM (9.86m³/min) | 1.000 in H2O (249.1 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 66.0dB(A) | - | 4500 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | - | - | 1.5 lbs (670.0 g) |
|
|
MS1751H48B1+6-FHR-2EMFAN AXIAL 171X51.5MM 48VDC WIRE |
0 |
|
데이터시트 |
MS1751-H | Bulk | Active | 48VDC | Rectangular/Rounded - 171mm L x 153mm H | 51.50mm | 418.0 CFM (11.70m³/min) | 1.640 in H2O (408.5 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 71.0dB(A) | - | 5500 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | - | - | 1.5 lbs (670.0 g) |
|
|
17250VA-24Q-GA-00DC AXIAL FAN |
0 |
|
데이터시트 |
17250VA | Box | Active | 24VDC | Round - 172.7mm Dia | 50.80mm | 304.0 CFM (8.51m³/min) | 1.072 in H2O (267.0 Pa) | Ball | Tubeaxial | Auto Restart | 58.0dB | 31.2 W | 4000 RPM | 2 Wire Leads | IP69K - Dust Tight, High Temp Water Jets, Waterproof | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
|
9HV1224A1D001120X38MM 24V, HIGH PERFORMANCE G |
0 |
|
데이터시트 |
San Ace 120 | Box | Active | 24VDC | Square - 120mm L x 120mm H | 38.00mm | - | - | Ball | Tubeaxial | Locked Rotor Sensor | - | - | - | 3 Wire Leads | - | - | cURus, TUV | - |
|
EFB1524VHGFAN AXIAL 172X50.8MM 24VDC WIRE |
0 |
|
데이터시트 |
EFB | Tray | Active | 24VDC | Rectangular/Rounded - 172mm L x 150mm H | 50.80mm | 302.3 CFM (8.46m³/min) | 0.937 in H2O (233.4 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 60.0dB(A) | 23.28 W | 4000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 1.9 lbs (861.8 g) |
|
|
109BJ12MA2FAN BLOWER 126X32MM 12VDC WIRE |
0 |
|
데이터시트 |
San Ace B127 | Box | Active | 12VDC | Square/Rounded - 126mm L x 127mm H | 32.00mm | 21.5 CFM (0.602m³/min) | 0.441 in H2O (110.0 Pa) | Ball | Blower | Locked Rotor Protection | 40.0dB(A) | 3.48 W | 1900 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.639 lb (289.85 g) |
|
|
109BJ24HA2FAN BLOWER 126X32MM 24VDC WIRE |
0 |
|
데이터시트 |
San Ace B127 | Box | Active | 24VDC | Square/Rounded - 126mm L x 127mm H | 32.00mm | 27.5 CFM (0.770m³/min) | 0.826 in H2O (205.8 Pa) | Ball | Blower | Locked Rotor Protection | 46.0dB(A) | 6.24 W | 2400 RPM | 2 Wire Leads | - | -4 ~ 140°F (-20 ~ 60°C) | CSA, TUV, UL | 0.639 lb (289.85 g) |
|
|
109BJ24MA2FAN BLOWER 126X32MM 24VDC WIRE |
0 |
|
데이터시트 |
San Ace B127 | Box | Active | 24VDC | Square/Rounded - 126mm L x 127mm H | 32.00mm | 21.5 CFM (0.602m³/min) | 0.441 in H2O (110.0 Pa) | Ball | Blower | Locked Rotor Protection | 40.0dB(A) | 3.6 W | 1900 RPM | 2 Wire Leads | - | -4 ~ 140°F (-20 ~ 60°C) | CSA, TUV, UL | 0.639 lb (289.85 g) |
|
|
8314HU-342DC TUBEAXIAL FAN |
0 |
|
데이터시트 |
8300U | Bulk | Active | 48VDC | Square - 80mm L x 80mm H | 32.00mm | 39.5 CFM (1.11m³/min) | - | Ball | Tubeaxial | - | 43.0dB(A) | 4.3 W | 4200 RPM | 2 Wire Leads | - | -4 ~ 167°F (-20 ~ 75°C) | CSA, CE, VDE, UL | - |
|
OD172SAPL-48HHBXCFAN AXIAL 172X38.5MM 48VDC WIRE |
0 |
|
데이터시트 |
OD172SAPL | Box | Active | 48VDC | Rectangular/Rounded - 172mm L x 150mm H | 38.50mm | - | - | Ball | Tubeaxial | Auto Restart | - | - | - | 2 Wire Leads | - | - | - | - |
|
|
109BJ12HC2FAN BLOWER 126X32MM 12VDC WIRE |
0 |
|
데이터시트 |
San Ace B127 | Box | Active | 12VDC | Square/Rounded - 126mm L x 127mm H | 32.00mm | 27.5 CFM (0.770m³/min) | 0.826 in H2O (205.8 Pa) | Ball | Blower | Locked Rotor Protection, Speed Sensor (Tach) | 46.0dB(A) | 6.24 W | 2400 RPM | 3 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.639 lb (289.85 g) |
